HOWO 6X4 6 CBM Concrete Mixer Truck With HW76 Cabin And ZF Steering ZZ1257N3241W

Name: HOWO 6X4 6 CBM Concrete Mixer Truck With HW76 Cabin And ZF Steering ZZ1257N3241W
Brand: SINOTRUK HOWO-7
Price: 1 USD

Buy cheap HOWO 6X4 6 CBM Concrete Mixer Truck With HW76 Cabin And ZF Steering ZZ1257N3241W product

Brand Name : SINOTRUK HOWO-7

Model Number : ZZ5257GJBN3641W

Certification : ISO/CCC

Place of Origin : JINAN CITY OF CHINA

MOQ : 1 UNIT

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 500 units/month

Delivery Time : 30-45 work days

Packaging Details : Nude

Model : ZZ1257N3241W

Cabin : HW76 Cabin

Gearbox : HW19710

Mixing Volume(M³) : 6m³

Discharging Speed(M³/min) : ≤2

Steel : 3mm,4mm,5mm

Contact Now

ZZ1257N3241W HOWO 6X4 6 CBM Concrete Mixer Truck with HW76 Cabin And ZF Steering

Description:

Concrete mixer truck is a special truck used to transport concrete for construction; because of its shape, it is often referred to as a field snail truck. These trucks are equipped with cylindrical stirrer to carry mixed concrete. In the course of transportation, the mixing drum will always be rotated to ensure that the concrete carried will not solidify. After the concrete is transported, the inner part of the mixing drum is usually flushed with water to prevent the hardening of the concrete from occupying space, so that the volume of the mixing drum becomes smaller and smaller.
Mixing Volume(M³):6m³
Stuffing Volume(%):59.3
Feeding Speed(M³/min):≥3
Discharging Speed(M³/min):≤2
Discharge Residue(%):≤0.2
Slump Scope(mm):50～220
Drum Speed( Min):0～16
Water supply Syste:400L/Pneumatic
Drum Material:8/16MnR
Steel:3mm,4mm,5mm
Packing:

Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland.The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
Competitive Advantage:

HOWO-7 6X4 9 CBM Concrete Mixer Truck is produced by SINOTRUK.The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Rich experience and well after-sale service.

Cubage	Pump(ARK PV089MHR)+Motor(ARK MF089V)+Reducer(TOP T60) Mixing Volume(M³):6m³ Stuffing Volume(%):59.3 Feeding Speed(M³/min):≥3 Discharging Speed(M³/min):≤2 Discharge Residue(%):≤0.2 Slump Scope(mm):50～220 Drum Speed( Min):0～16 Water supply Syste:400L/Pneumatic Drum Material:8/16MnR Steel:3mm,4mm,5mm
Weight in kg	Kerb weight (Kg)			13700
	Gross vehicle weight (Kg)			30000
Dimension(mm)	Dimensions(mm)	Length(mm)		8715
		Width(mm)		2550
		Height(mm)		3950
	Wheel base (mm)			3600+1350
Performance	Maximum driving speed (km/h)			92
	Fuel consumption (1/100 km)			38
Cab	Model		SINOTRUK HOWO HW76 cab
			single bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner
Engine	Model		WD615.47(Euro 2)
	Type		6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
	Horsepower		371
	Maximum output Kw/r/min		272/2200
	Maximum torque N.m/r/min		1350/1300-1600
	Bore x Stroke		126x130mm
	Valve		2
	Displacement		9.726L
	Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80℃ opening begin, Rigid fan
Transmission	SINOTRUK HW19710 transmission ,10 forward and 2 reverse
Clutch	Φ430 diaphragm-spring clutch,hydraulically operating with air assistance
Steering	ZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)
Front Axle	SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes.
Rear Axles	SINOTRUK HC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:4.8;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.
Brake System	Service brake:dual circuit compressed air brake Parking brake (emergency brake):spring energy,compressed air operating on rear wheels
Wheels & Tyres	Rims:10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.
Electrics	Operating voltage:24V,negative grounded 24V,7.5KW.Starter:24V,7.5 Kw 28V,1500W.Alternator:3-phase,28V,1500 W Batteries:2x12 V,165 Ah horn,headlamps,fog lights,brake lights,indicators and reverse light
Oil Tank	Square type-400L Aluminum alloy fuel tank

HOWO 6X4 6 CBM Concrete Mixer Truck With HW76 Cabin And ZF Steering ZZ1257N3241W
